Mounted Atomizer Twister Espaldera

HP requirement: from 27 HP.

Available width: from 145 to 153 cm.

Tank Capacity: 600, 800, 1000 and 1200 litres


  • MAXIMUM VERSATILITY: Thanks to the upper and lower antibiotic tips, it is possible to combine the use of this atomizer, specifi cally designed for backyard vineyards, for the treatment of plots with trees and vineyards in glass.
  • GREAT ROBUSTNESS: Thanks to its robust design and simple shapes, we avoid mechanical problems and breakage caused by vegetation, as occurs in applications of nebulizers with braces.
  • RAPIDITY IN THE APPLICATION: The high speed of advance and great maneuverability allow to reduce the time of application obtaining the maximum performance.
  • HIGH EFFICIENCY: The Twister technology allows the possibility of processing four half faces in a single pass.
  • Structural tube frame cold rerolling
  • Polyethylene main tank with level indicator
  • Polyethylene or polyester hand-washing and circuit-washing tank Multiple fi ltering system
  • Multiple filtering system
  • Hydraulic stirrer
  • Piston pump high pressure Máñez Lozano
  • Manual control with pressure regulator and pressure gauge
  • Transmission between pump and turbine by cardan Outer and tractor conexión Category 3 SAE G4

Technical specifications

The Twister diff users produce a turbulent air fl ow in spiral form that generate the movement of the foliar mass, thus avoiding the screen eff ect and penetrating eff ectively into the interior of the tree

  • Ventilation Mañez Lozano Ø820 mm with nozzle and counter-propeller in stainless steel with 18 blades, which ensure a homogeneous distribution of air volume
  • Twister diff users with 36 anti-drop nozzle holders with turbulence nozzles
  • Multiplier Mañez Lozano with two speeds and neutral capable of transmitting great power
  • Triple air channeling system, prevents rapid air from the peripheral part collides with the slow air generated in the central part, increasing the efficiency of the fan
  • Eight adjustable aerodynamic design blades that increase performance, reduce consumption and noise level
  • Duralumin helical core with steel jacket to prevent wear due to friction with the clutch
  • Aluminum ferrule centrifugal clutch that allows a smooth and progressive start

Air system characteristics


Pump specially designed for atomizers.

8138730 mando on off ROJO recortado


Control with double switch to increase or decrease pressure (optional) and two switches to activate or deactivate the left and right solenoid valves.

mando tronic 1


The Tronic volumetric control is able to apply the l/Ha required for each treatment with respect to the forward speed.
3.2 “ (320X240) TFT colour screen which allows you to view all functions simultaneously
Identifi cation of electrical faults with on-screen alarms
Agenda that allows us to work with 50 diff erent fi elds and 15 diff erent treatments.
