Simple Cannon

HP requirement: from 34 Cv.

Available width: from 197 to 230 cm.

Tank Capacity: 1000, 1500, 2000 and 3000 litres

These cannons with a centrifugal group concentrate the air flow, achieving a wide range both vertically and horizontally.
They incorporate multiplier with two speeds and neutral, as well as clutch.

It has a 90º vertical rotation and 360º horizontal rotation

  • Double structural tube frame
  • Telescopic drawbar
  • Side step for reaching tank filler lid
  • Jockey wheel for parking sprayer
  • Fiberglass tank with level indicator and internal baffles tank
  • Fiberglass tank for hand wash and system rinse
  • Multiple filtering system
  • Products mixer
  • Cleaning robot inside the main tank
  • Hydraulic stirrer
  • Mañez Lozano high pressure piston pump with reduction shaft
  • ON/OFF electric control unit
  • Through tank pto class 4 SAE
  • Tractor PTO category 4 SAE G7

Technical specifications

  • Centrifugue wheel 500 fire painting
  • Two speeds and neutral gearbox transmission
  • Aluminium clutch linings
  • Double dripless nozzle with ceramic and cone spray tips

Air system characteristics

PUMP SUPER REDUCTORA ML-A1

Pump specially designed for atomizers. This pump is mounted with a reducer and a through shaft : the through shaft allows us to directly transmit the revolutions of the tractor joint shaft to the air system, and the reducer decreases the revolutions of the pump crankshaft , lowering the power absorption and, therefore, both the fuel consumption and wear of the pump.

PUMP SUPER DIRECTA ML-A

Pump specially designed for atomizers.

PUMP ESPECIAL DIRECTA ML-D

Pump specially designed for atomizers.

mando-M170-2

MANUAL CONTROL M-170

Manual control with a selector lever for selecting the sections you wish to apply treatment. You can also regulate the working pressure precisely and reliably by turning the handle even while operating.

8138730 mando on off ROJO recortado

ELECTRIC CONTROL ON-OFF

Control with double switch to increase or decrease pressure (optional) and two switches to activate or deactivate the left and right solenoid valves.

OPTIONAL EQUIPMENT
